恒流调光器
Available in six-channel and twelve-channel versions, the DMX2CC enables DMX512 control of high power LEDs (1 W and 3 W) using a constant current dimming method, ensuring flicker-free and smooth dimming as it is, for instance, required in such environments as television studios or in the field of medicine. The DMX512 out port repeats and amplifies the DMX512 signal for convenient daisy-chaining. Additionally, a self-diagnostic test function prevents damage to the unit and LEDs caused by incorrect wiring, open or short circuit, and overheating, and is able to maintain lighting levels in times of DMX512 data and signal loss. DMX2CC is easily set up with auto and manual DMX512 addressing modes, and conveniently mountable inside equipment racks using standardized 35 mm wide DIN rail.
IC 6 Channel: AA5700601IL
EAN 6 Channel: 4006584812356
IC 12 Channel: AA5700501IL
EAN 12 Channel: 4006584812332
Certifications & Approbations
| DMX2CC 12 通道 | DMX2CC 6 通道 | |
| 尺寸 (W x H x D) | 272 x 75.4 x 58.5mm / 10.71 x 2.97 x 2.3 英寸 | 142 x 75.4 x 58.5mm / 5.59 x 2.97 x 2.3 英寸 |
| 重量 | 0.75 克/1.65 磅lb | 412 克/0.9 磅 |
| 电源 | 24 … 48V DC 最大。9 A |
24 … 48V DC 最大。4.5 A |
| 静态电流 | 24 V：140 mA 48 V：80 mA |
24 V：80 mA 48 V：50 mA |
| 工作温度 | -10 … 40°C / 14 … 104°F | -10 … 40°C / 14 … 104°F |
| 存储温度 | -20 …70°C / -4 … 158°F | -20 …70°C / -4 … 158°F |
| 工作湿度 | 20 …90%RH, 非冷凝 | 20 …90%RH, 非冷凝 |
| 外壳 | 阳极氧化铝和塑料 | 阳极氧化铝和塑料 |
| 认证 | CE, FCC, TUV、UKCA | CE, FCC, TUV、UKCA |
| 输入 | DMX512 ( )RJ45 | DMX512 ( )RJ45 |
| 输出 | DMX512 ( ) 用于连锁多个设备 12 x 输出通道（螺丝端子）RJ45 | DMX512 ( ) 用于连锁多个设备 6 x 输出通道（螺丝端子）RJ45 |
