| Dimensions (W x H x D) |
170 x 53.4 x 28 mm / 6.69 x 2.09 x 1.1 in |
| Weight |
170 g |
| Power input |
12 … 48 V DC (4-pin terminal) |
| Operating Temperature |
-20 … 50 °C / -4 … 122 °F |
| Storage Temperature |
-40 … 85 °C / -40 … 185 °F |
| Operating Humidity |
5 … 95% RH, non-condensing |
| Housing |
PC |
| Certification |
CE, UKCA, RoHS, UL Listing pending |
| Input |
1 x DMX512 / RDM (3-pin terminal), isolated, surge protected |
| Output |
1 x DMX512 / RDM (3-pin terminal) for chaining multiple devices (max. 256), isolated, surge protection
4 x constant current channel (5-pin terminal)
+ connector: identical to input voltage
– connector: low side switch |
| Output current |
100 … 700 mA per channel, selectable with 10mA increment |
| Output voltage |
3 … 12V @ 12V input,
3 … 24V @ 24V input,
3 … 48V @ 48V input
|
| Output power |
1.2 … 25.2 W @ 700 mA per channel |
| Output dimming curve gamma |
0.1 … 9.9 |
| Connection type |
Spring terminal connectors |
